Product Feature:
Studies have shown that in conveyors, belt is an important component to address the risk of personnel and installations in an industry. The effect of fire is devastating in terms of losses, both tangible and intangible.
The components of conveyor belt are combustible and can be a medium to propagate fire in an unlikely event. With the advancement in technology, and after much R & D we have been able to impart properties to conveyor belts so that that the fire can be limited at source.
This has been achieved by using a combination of polymers, chemical and additives which can be added to improve the fire retardant properties of the belt without compromising the wear life of the belt.
In order to cater to carrying levels of fire resistance we have developed a range of belts which are in adherence to various domestic and international standards.
- The usage reduces the risk of fire hazard and the potential loss of human life, material and installation.
- The belts are easy to splice.
- The belts are Anti-Static.
Archana FR belts are commonly used in handling coal over ground in coal mines and thermal power plants. They are also used for any materials which are prone to ignition during the process of conveying.
Industries:
Coal Mines |Ore Mines |Ports |Thermal Power Plants |Coal prep plants
|
CONSTRUCTIONAL FEATURES |
|
|
Width |
Up to 1500 mm |
|
Length |
As per requirement |
|
Ends |
Open or Endless |
|
Edge |
Cut or Moulded Edge |
|
Fabric Plies |
1 ply to 7 ply |
|
Carcass Construction |
EP/NN/PP |
|
Cover Thickness |
1.5 mm to 250 mm |
|
Cover Grades |
Refer the chart |
|
Common Belt Rating |
200 to 3150 kN/m |
|
Splicing Method |
Hot/Cold/Mechanical |
|
Fire Resistant test Compliance to Standard |
Minimum Tensile Strength (Mpa) |
Minimum Elongation at Break (%) |
Maximum Abrasion Loss (mm³) |
Application Characteristics |
Reference Material |
|
FR MSHA 2G |
15 |
350 |
190 |
Moderate resistance to flame for over ground application |
Coal, Grains, Ore, etc. |
|
FR CAN-C |
17 |
400 |
175 |
Good resistance to flame for over ground applications |
Coal Mines, Ore Mines, Ports, thermal Power Plants, Coal prep plants |
|
FR DIN K |
17 |
400 |
175 |
||
|
FR IS 1891 |
17 |
400 |
175 |
||
|
FR 110 |
17 |
400 |
110 |
Good resistance to flame, moderate oil and heat for over ground applications |
Handling large lumps of coal and other ores |
|
FR OR - CAN C |
14 |
400 |
200 |
Good resistance to flame, moderate Oil and heat for over ground application |
Pet Coke, grains |
|
HR FR OR – CAN C |
17 |
400 |
175 |
||
|
HFFR- CAN C |
12.5 |
350 |
230 |
Halogen free, low smoke, good fire resistance belt for over ground applications |
Coal conveying in presence of Gamma radiation based calorific value of Coal detection system |
|
FR - AS F |
17 |
400 |
175 |
Very good resistance to flame, suitable for high risk over ground/low risk underground applications |
Coal, ore mines |
|
FR - DIN S |
17 |
400 |
175 |
||
|
FR – SANS 971:2003 |
15 |
400 |
175 |
||
|
FR MSHA BELT (PART 14) |
15 |
400 |
200 |
Excellent resistance to flame propogation, suitable for underground mining operations |
Underground coal mines and high fire risk applications |
Note:
For any specific cover grade requirement outside the chart, kindly contact the Archana’s Technical Division
The Archana FR range of belts are in adherence to major Fire Resistant standards across markets like:
FRAS S as per AS 4606:2012 | SANS 971:2013 |DIN 22103 |EN ISO14973:2006 |IS 1891: Part 5 |CAN CA M22-12
